3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells

3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells
3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells 3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells 3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells 3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells

Large Image :  3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells

Product Details:
Place of Origin: China
Brand Name: OEM
Model Number: ER10450
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Bargain
Packaging Details: cartons
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000pcs/days

3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells

Description
Capacity: 0.8 Ah Max. Continuous Current: 25mA
Max. Pulse Current: 60mA Weight: Approx 9 G
Type: Non Rechargeable Cell PCM: No
SMT For PCB: Yes Package: Carton
High Light:

AAA LR03 Lithium Cylinder Battery

,

800mAh Lithium Cylinder Battery

,

Li SOCl2 Primary Cells


Model:Lithium Thionyl Chloride Battery 3.6V 800mah AAA size dispossable battery

Technical data:


Model ER10450
Voltage 3.6V
Capacity 800mAh
Max constant current of discharge 25mA
Max discharge current(pulse) 60mA
Weight 9g
Operating temperature range -55~85℃
Jacket PVC or Plastic case
Terminals Pins/tabs/customized
Samples Available
Color Blue or customized LOGO
OEM and ODM Welcome



Application:

Utility Metering

Automatic Meter Reading

Medical Electronics

Memory Backup

Tracking Systems

Law Enforcement (RFID)

Earthquake Detectors

Digital Control Devices

Remote Monitory Systems

Electronic Toll Tags

Scientific Instruments

Portable Communication Equipment

Military Radio Stations

And other electric powered devices requiring small size

High power batteries.

3.6V 800mAh AAA LR03 Lithium Cylinder Battery Li SOCl2 Primary Cells 0

Lithium Thionyl Chloride Battery 3.6V List:


International Model Size Model Number Max Dimension Weight Nominal End Voltage Nominal Capacity Max Continuous Operating Current Max Pulse Discharge Current
mm g Voltage V mAh mA mA
AAA ER10450 φ10.4X45.3 8 3.6 2 600(1mA) 25 60
  ER11120 φ11.5X12.0 2 3.6 2 100(0.2mA) 2 4
  ER13150 φ13.5X15.0 6 3.6 2 450(0.5mA) 10 30
L31 ER13460 φ13.5X46.0 14 3.6 2 1500(1mA) 60 100
1/2AA ER14250 φ14.5X25.0 10 3.6 2 1200(0.5mA) 20 45
2/3AA ER14335 φ14.5X33.5 13 3.6 2 1650(1.3mA) 75 150
AA ER14505 φ14.5X50.5 22 3.6 2 2400(2mA) 100 200
2/3A ER17335 φ17.0X33.5 21 3.6 2 2100(2mA) 100 200
  ER17505 φ17.0X50.5 25 3.6 2 3400(4mA) 120 200
A ER18505 φ18.8X50.5 30 3.6 2 4000(2mA) 120 200
C ER26500 φ26.2X50.0 53 3.6 2 8500(3mA) 130 300
D ER34615 φ34.0X61.5 108 3.6 2 19000(2mA) 200 400

International Model Size Model Number Max Dimension Weight Nominal End Voltage Nominal Capacity Max Continuous Operating Current Max Pulse Discharge Current
mm g Voltage V mAh mA mA
1/2AA ER14250M φ14.5X25.2 10 3.6 2 750(4mA) 120 250
2/3AA ER14335M φ14.5X33.5 13 3.6 2 1200(4mA) 300 500
AA ER14505M φ14.5X50.5 22 3.6 2 1800(10mA) 500 1000
2/3A ER17335M φ17.0X33.5 21 3.6 2 1700(5mA) 500 1000
A ER18505M φ18.8X50.5 30 3.6 2 3200(10mA) 800 1500
C ER26500M φ26.2X50.0 53 3.6 2 6500(10mA) 1000 2000
D ER34615M φ34.0X61.5 108 3.6 2 14000(10mA) 2000 3000
Application:Utility Metering, Automatic Meter Reading, Medical Electronics, Memory Backup, Tracking Systems, Law Enforcement (RFID), Earthquake Detectors, Digital Control Devices, Remote Monitory Systems, Electronic Toll Tags, Scientific Instruments, Portable Communication Equipment, Military Radio Stations, and other electric powered devices requiring small size, high power batteries.
