Product Details:
|
| Shape: | Button Cell | Material: | Litium Manganese Dioxide Battery |
|---|---|---|---|
| Part Number: | CR2032 | Voltage: | 3.0V |
| Package: | Cartons | Printing: | Customized |
| High Light: | CR2032 Primary Lithium Battery,Button Cell Primary Lithium Battery,Cmos Lithium Coin Cell |
||
Original CR2450 CR2032 CR2025 CR1632 CR2016 Primary Lithium Battery Cmos Lithium Button Coin Cell Bateria Watch Battery
CR2032 popular brand battery CR2032 CR 2032 DL2032 3V lithium button cell
Cuanen CR2032 batterie 3V CR 2032 piles bouton au Lithium pour montre télécommande
3V Cr 2032 Cr2025 Cr2016 Cr1620 Cr2450 H Cmos Pile Batterie Pilas Box Lithium Button Coin Cell Bateria Watch Battery
CR2032 3V Lithium batterie mit Schweiß laschen für Spiele CR2032 CR2025 CR1616 Knopfzellen batterie mit Kinder bab
Cell Battery 3V CR2477 CR2450 CR2430 CR 2335 CR2330 CR2032 CR2020
4 X CR2032 button cell 3V Lithium battery button battery
| Item | Unit | Secification | Conditions |
| Voltage | V | 3.0 | Standard discharge |
| Capacity | Mah | 240 | Standard discharge |
| Instandtaneous Short-circuit current | mA | ≥250 | Time≤0.5 second |
| Off-load voltage | V | ≥3.25 | |
| Storage temperature | ℃ | -10~50 | |
| Standard weight | g | 3.0 | Unit cell |
| Self-discharge rate |
≤5% | Stored for 12 months at normal temperature, then continuously discharged with 15 load till 2.0v end-voltage |
| ITEM | CONDITIONS | CHARACTERISTICS |
| Self-discharge rate | Stored for 12 months at normal temperature, then continuously discharged with 15kΩ load till 2.0v end-voltage | ≤5% |
Suggestions And Cautions
1 Install batteries correctly.
2 Ensure the contact points to be clean and conductive.
3 Do not mix different types, different brands batteries to serve together.
4 Do not heat, recharge the batteries.
5 Do not dispose of the batteries in fire.
6 Keep away from the small children, if swallowed promptly see doctor.
7 Pay attention to the producing date.
Coin Cell Battery Application:
Widely used in watches,computers, laptops, music card;
Voice table,hearing aids, electroni cnotepads, dict;
Cameras, medical devices, flashing lights;
Shoes, lamps and other electronic products.
Such as:
Vacuum cleaner, shaver, MP3, MP4, Digital camera, portable computer,
Lighting, electrical toys, electronic game Machine and electrical vehicles,
Cordless Phones, interphones, and all kinds of Cell phones.
Advantage for Button Cell Battery Lithium Limno2:
High capacity and long cycle life
Long service lifespan
Excellent life cycle
Enviromental friendly
High energy density
Excellent overcharge performance
Rapid charge performance
Lower inner resistance and low self-discharge
Safety and reliability
Wide temperature range, specially design battery can used in high and low temperature
Good quality with competitive price and best service
3.0v Button cell:
| Mode | Voltage(V) | Capacity(mAh) | Dimension(mm) | Weight(g) | Chargeable or Non |
| CR2032 | 3 | 220 | 20.0*3.2 | 3 | Non |
| CR2032 | 3 | 240 | 20.0*3.2 | 3 | Non |
| CR1220 | 3 | 35 | 12.5*2.0 | 0.8 | Non |
| CR1225 | 3 | 50 | 12.5*2.5 | 0.9 | Non |
| CR1616 | 3 | 50 | 16.0*1.6 | 1.1 | Non |
| CR1620 | 3 | 70 | 16.0*2.0 | 1.3 | Non |
| CR1632 | 3 | 120 | 16.0*3.2 | 1.8 | Non |
| CR2016 | 3 | 83 | 20.0*1.6 | 1.7 | Non |
| CR2025 | 3 | 150 | 20.0*2.5 | 2.5 | Non |
| CR2450 | 3 | 600 | 24.5*5.0 | 6.2 | Non |
| CR3032 | 3 | 550 | 30.0*3.2 | 7 | Non |
| ML1220 | 3 | 17 | 12.5*2.0 | 0.8 | Yes |
