Product Details:
|
| Cell Model: | Can Be 18650/26650/21700/14500/34120/32700 | Combination: | Depends On Your Needed |
|---|---|---|---|
| Voltage: | 12v | Capacity: | 10ah |
| PCM: | Yes | Termianls: | Welcome Customized |
| High Light: | Rechargeable 12V 10Ah LiFePO4 Battery,Deep Cycle 12V 10Ah LiFePO4 Battery |
||
12V 10Ah Lithium LiFePO4 Deep Cycle Rechargeable Battery 12-volt 10Ah battery designed LiFePO4
12V 10Ah Battery – Lightweight LiFePO4 Battery
we specialize in delivering high-performance 12V lithium batteries.
Our 12v 10ah battery can be customized as reliable LiFePO4 battery or lithium ion battery.
This battery is the best choice for replacing lead acid battery.
Product Description:
1. Model Number: LFP12V10Ah
2. Nominal Capacity: 10Ah
3. Nominal Voltage: 12.8V
4. MAX Charge Voltage: 14.6V
5. MAX Charge Current: 10A(Customization)
6. The Max connection in series / in parallels: Support 4 series and 4 parallel
7. Customization Support: Including voltage, capacity, current, size, appearance, etc.
12V 10Ah LFP Battery
Our 12V 10Ah LiFePO4 Battery is a state of the art 12V 10Ah rechargeable battery pack with high power, excellent safety performance, low self-discharge rate, and lightweight.
It is perfect for e-scooters, e-bikes, solar applications, robots, and other applications that require a higher energy density battery.
The battery comes with integrated Anderson Power...
|
Specifications |
12V7Ah |
12V12Ah |
12V20Ah |
|
Nominal Voltage |
12.8V |
12.8V |
12.8V |
|
Nominal Capacity(C/5,23℃) |
7Ah |
12Ah |
20Ah |
|
Max output current(30S) |
21A |
30A |
30A |
|
Max Cont Discharge current |
7A |
12A |
20A |
|
Discharge Cut-off Voltage |
10V |
10V |
10V |
|
End of Charge voltage |
14.6V |
14.6V |
14.6V |
|
Float Voltage |
13.8V |
13.8V |
13.8V |
|
Recommended charging current |
3.5A |
6A |
10A |
|
Terminals |
VRLA6.3mm |
VRLA6.3mm |
M6 |
|
Dimension |
151x65x95mm |
151x98x95mm |
181.5x77x166 |
Made with 18650 cell as follow:
| Model | Capacity | Min. capacity | Continuous discharge | Internal resistance | Certificate |
| 18650F56 | 2200 | 2180mAh | 1C | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F8R | 2600 | 2550mAh | 1C(2550mA) | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F9L | 3350 | 3250mAh | 0.5C (1625mA)(-20~5℃) 1.5C (4875mA)(5~50℃) |
≤ 60mΩ | ULCBBISUNBSMI |
| 18650F30 | 3000 | 2900mAh | 1C | ≤ 60mΩ | ULCBBISUNBSMI |
| 18650F30P | 3000 | 2900mAh | 20A 30A |
≤ 18mΩ | ULCBBISUNBSMI |
| 21700F2E | 5000 | 4900mAh | 3.0C(14400mA) |
≤ 25mΩ | ULCBBISUNBSMI |
| 18650F8L | 2600 | 2500mAh | 3C | ≤ 25mΩ(≥ 4.15V) | ULCBBISUNBSMI |
| 18650F8M7 | 2600 | 2500mAh | 3C | ≤ 30mΩ | ULCBBISUNBSMI |
| 18650F8P | 2500 | 2500mAh | 20A 30A |
≤ 18mΩ | ULCBBISUNBSMI |
| 18650F9E | 3500 | 3450mAh | 10000mA | ≤ 40mΩ | ULCBBISUNBSMI |
| 18650F9M | 3200 | 3100mAh | 3.0C(9300mA) | ≤ 40mΩ | ULCBBISUNBSMI |
Function of Lithium Battery
Bluetooth Function
Lithium Battery technology offers high-powered cell performance compatible with lots of lithium-ion application to deliver more power and extend long life. Also built with bluetooth function allow you to read battery status freely anytime.
Self-heated Function
To relieve winter range anxiety in some freezing environment, the BMS can bring with self heating function. Resistance heating rapidly warms the inside of battery. Start heating temperature:≤0°C. Stop heating temperature:≥10°C. Can improve battery charge / discharge performance.
Hot sale model 18650 / 26650
| Cell model | Voltage/V | Capacity/mAh | Capacity/mAh | Charge current | Discharge current | |||
| Standard | Max. | Standard | Rapid | Max. | ||||
| IFR18650-1600mAh-3.2V | 3.2 | 1600 | ≥1550 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR18650-1800mAh-3.2V | 3.2 | 1800 | ≥1750 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3200mAh-3.2V | 3.2 | 3200 | ≥3100 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3600mAh-3.2V | 3.2 | 3600 | ≥3550 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3800mAh-3.2V | 3.2 | 3800 | ≥3750 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-4000mAh-3.2V | 3.2 | 4000 | ≥3950 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFRP18650-1100mAh-3.2V | 3.2 | 1100 | ≥1050 | 2C | 5C | 5C | 10C | 30C |
| IFRP26650-3000mAh-3.2V | 3.2 | 3000 | ≥2900 | 1C | 3C | 2C | 5C | 10C |
| INR18650-2200mAh-3.6V | 3.6 | 2200 | ≥2150 | 0.5C | 1C | 0.5C | 1C | 3C |
| INR18650-2600mAh-3.6V | 3.6 | 2600 | ≥2550 | 0.3C | 0.5C | 0.5C | 1C | 2C |
| INR26650-5000mAh-3.6V | 3.6 | 5000 | ≥4900 | 0.5C | 1C | 0.5C | 1C | 2C |
Application of Lithium Battery
⇒ UPS, Solar, Wind, Mobile generator, Back up power
⇒ Solar power bank, Solar LED lighting, Solar street light
⇒ Scooter, E-bike, Golf cart, E-motor, E-tour car, tricycle
⇒ Electric drill, electric saw, lawn mower and so on
⇒ Remote control cars, boat, aircraft, toys
⇒ Medical devices, equipment and portable equipment
⇒ Bluetooth, GPS, Wearable device, Power supply, Wireless
1. Back-up System and UPS: Telecom Base / CATV system / Computer Server Center / Medical Instruments / Military Equipment.
2. Energy Storage: Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome / Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Vehicle.
3. Other Applications: Security and Electronics / Mobile POS, Mining Light/ Torch / LED Light / Emergency Light / LED Backup / Engine Starting Battery,etc.
The lifepo4 battery pack is widely used for RV, Camper, Yacht, Golf cart, Solar energy storage system, electric bicycle, electric bike, electric wheelchair, power tools, electric scooter,emergency light,etc
Warning & Tips
1. Keep the battery against high temperature. Otherwise it will cause battery heat, get into fire or lose some functions and reduce the life;
2. When the battery run out of power, please charge it within 15 days；
3. Please use the original or recommended charger for this battery;
4. If the battery leaks and get into the eyes or skin, do not wipe, instead, rinse it with clean water and see doctor immediately;
