Place of Origin:
China
Brand Name:
OEM
Model Number:
3.0v thin batteries
Thin cell list:
Model Size | Nominal Voltage | Nominal Capacity | Max Continuous Discharge Current | Max Pulse Discharge Current | Dimension | ||
T(mm) | W(mm) | H(mm) | |||||
CP042345 | 3V | 35mAh | 2mA | 4mA | 0.45 | 23±0.5 | 45±0.5 |
CP042529 | 3V | 22mAh | 2mA | 4mA | 0.45 | 25±0.5 | 29±0.5 |
CP042722 | 3V | 15 mAh | 1mA | 2mA | 0.45 | 27±0.5 | 22±0.5 |
CP042922 | 3V | 15mAh | 1mA | 2mA | 0.41 | 29 | 23 |
CP044040 | 3V | 50mAh | 5mA | 10mA | 0.45 | 40 | 40±0.5 |
CP044560 | 3V | 100mAh | 10mA | 20mA | 0.45 | 45.5 | 60 |
CP052039 | 3V | 25 mAh | 2 mA | 4 mA | 0.5 | 20 | 39 |
CP052722 | 3V | 22mAh | 1mA | 2mA | 0.5 | 27 | 22 |
CP053050 | 3V | 80mAh | 15mA | 30mA | 0.5 | 30 | 50 |
CP054248 | 3V | 100mAh | 20mA | 40mA | 0.5 | 48.5±0.5 | 48.5±0.5 |
CP064348 | 3V | 200mAh | 20mA | 50mA | 0.6 | 48.5±0.5 | 48.5±0.5 |
CP073545 | 3V | 160mAh | 10mA | 20mA | 0.7 | 35 | 45 |
CP082922 | 3V | 50 mAh | 20mA | 80mA | 0.8 | 29 | 22 |
CP084248 | 3V | 320mAh | 20mA | 50mA | 0.8 | 48.5±0.5 | 48.5±0.5 |
CP102015 | 3V | 30mAh | 2mA | 5mA | 1 | 20±0.5 | 15±0.5 |
CP104248 | 3V | 420mAh | 100mA | 200mA | 1.05 | 49 | 49 |
CP105050 | 3V | 420mAh | 100mA | 200mA | 1.05 | 50 | 50 |
CP105075 | 3V | 450mAh | 200mA | 300mA | 1.05 | 45.2 | 75 |
CP105256 | 3V | 500mAh | 30mA | 50mA | 1.05 | 52 | 56 |
CP124444 | 3V | 420 mAh | 75 mA | 150mA | 1.2 | 44 | 44 |
CP142828 | 3V | 160mAh | 25mA | 50mA | 1.4 | 28±1.0 | 28±1.0 |
CP142828H | 3V | 140mAh | 50mA | 100mA | 1.4 | 28±1.0 | 28±1.0 |
CP151220 | 3V | 35mAh | 5mA | 10mA | 1.5 | 12±0.5 | 20±0.5 |
CP153030 | 3V | 170mAh | 40mA | 80mA | 1.5 | 30 | 30 |
CP153030H | 3V | 140mAh | 50mA | 100mA | 1.5 | 30 | 30 |
CP154580 | 3V | 1000mAh | 150mA | 300mA | 1.5 | 45±0.5 | 80 |
CP151015 | 3V | 18mAh | 0.5mA | 1mA | 1.5 | 10±0.5 | 15±0.5 |
CP161220H | 3V | 20mAh | 16mA | 30mA | 1.6 | 12±0.5 | 20±0.5 |
CP161230H | 3V | 45mAh | 16mA | 30mA | 1.6 | 12±0.5 | 30±0.5 |
CP162235 | 3V | 160mAh | 30mA | 50mA | 1.6 | 22 | 35 |
CP164548 | 3V | 700mAh | 50mA | 100mA | 1.6 | 45.5 | 48.5 |
CP171234 | 3V | 140mAh | 20mA | 50mA | 3.6 | 35 | 13.5 |
CP181234 | 3V | 125mAh | 25mA | 50mA | 1.8 | 12±0.5 | 34 |
CP183123 | 3V | 150mAh | 45mA | 75mA | 1.8 | ||
CP201335 | 3V | 120mAh | 25mA | 50mA | 2 | 10 | 35 |
CP201535 | 3V | 120mAh | 30mA | 60mA | 1.9 | 14 | 35 |
CP202128 | 3V | 130mAh | 20mA | 40mA | 2 | 21±0.5 | 28±0.5 |
CP202540 | 3V | 350mAh | 75mA | 150mA | 2 | 25±0.5 | 40±0.5 |
CP202721 | 3V | 140mAh | 40mA | 80mA | 2 | 27±0.5 | 21±0.5 |
CP203030 | 3V | 230mAh | 50mA | 100mA | 2 | 30 | 30 |
CP203034 | 3V | 275 mAh | 50 mA | 100mA | 2 | 30 | 34 |
CP203040 | 3V | 210mAh/380MAH | 100mA | 200mA | 2 | 30±0.5 | 40±0.5 |
CP203242 | 3V | 375mAh | 75mA | 150mA | 2.1 | 32 | 42 |
CP204517 | 3V | 210mAh | 20mA | 50mA | 2 | 45±0.5 | 17±0.5 |
CP204547 | 3V | 750mAh | 50mA | 100mA | 2 | 45±0.5 | 47±0.5 |
CP222920 | 3V | 150mAh | 45mA | 75mA | 2.2 | ||
CP224248 | 3V | 850mAh | 100mA | 200mA | 2.2 | 45±0.5 | 48.5±0.5 |
CP225050 | 3V | 1000mAh | 200mA | 400mA | 2.2 | 50 | 50 |
CP225080 | 3V | 1700mAh | 200mA | 400mA | 2.2 | 50 | 80 |
CP242030 | 3V | 230mAh | 50mA | 100mA | 2.4 | 20±0.5 | 30±0.5 |
CP255050 | 3V | 1200mAh | 150mA | 300mA | 2.5 | 50 | 50 |
CP251525 | 3V | 150mAh | 40mA | 80mA | 2.5 | 15±0.5 | 25±0.5 |
CP251626 | 3V | 150mAh | 60mA | 150mA | 2.5 | 16±0.5 | 26.5±0.5 |
CP252525 | 3V | 250mAh | 30mA | 60mA | 2.5 | 25.5 | 25.5 |
CP255047 | 3V | 1250mAh | 150mA | 300mA | 2.5 | 50 | 47.5±0.5 |
CP255080 | 3V | 2050mAh | 300mA | 600mA | 2.5 | 50 | 80 |
CP301415 | 3V | 85mAh | 30mA | 60mA | 3 | 14±0.5 | 15±0.5 |
CP301919-2S | 6V | 150mAh | 50 mA | 100mA | 6.1 | 19.5 | 19.5 |
CP302525 | 3V | 350mAh | 75 mA | 150 mA | 3 | 25 | 25 |
CP304580 | 3V | 2500mAh | 200mA | 500mA | 3 | 45 | 80 |
CP321626 | 3V | 250mAh | 50mA | 100mA | 6.1 | 19.5 | 19.5 |
CP334728 | 3V | 700mAh | 100mA | 200mA | 3.5 | 47.5 | 28.0±0.5 |
CP352440 | 3V | 750mAh | 100mA | 300mA | 3.5 | 24.5 | 41 |
CP355050 | 3V | 2000mAh | 500mA | 1000mA | 3.5 | 50 | 50 |
CP402020 | 3V | 275mAh | 50mA | 100mA | 4 | 20±0.5 | 20±0.5 |
CP402424H | 3V | 400mAh | 100mA | 300mA | 4 | 24 | 24 |
CP403030 | 3V | 550mAh | 75mA | 150mA | 4 | 30 | 30 |
CP453450 | 3V | 1700mAh | 300mA | 600mA | 4.5 | 33±0.5 | 49±0.5 |
CP501525 | 3V | 350mAh | 80mA | 150mA | 5 | 15±0.5 | 25.5±0.5 |
CP502440 | 3V | 1200mAh | 150mA | 300mA | 5 | 24.5±0.5 | 41 |
CP502540 | 3V | 1200mAh | 150mA | 300mA | 5.2 | 42 | 25.5 |
CP503436 | 3V | 1550mAh | 200mA | 500mA | 5.2 | 34.5 | 36 |
CP503740 | 3V | 1700mAh | 300mA | 600mA | 5 | 37±0.5 | 40±0.5 |
CP503742 | 3V | 1700mAh | 300mA | 600mA | 5 | 37±0.5 | 42±0.5 |
CP505050 | 3V | 3000mAh | 500mA | 1500mA | 5.2 | 50.5±0.5 | 50.5±0.5 |
CP505050-2S | 6V | 3000mAh | 600mA | 1800mA | |||
CP505050-2P | 3V | 6000mAh | 1000mA | 2000mA | 10.3 | 50.5 | 50.5 |
CP543537 | 3V | 1500mAh | 200mA | 400mA | 5.6 | 35.5 | 37 |
CP601919 | 3V | 300mAh | 100mA | 200mA | 6.1 | 19.5 | 19.5 |
CP603450 | 3V | 2400mAh | 500mA | 1000mA | 6.1 | 34±0.5 | 50±0.5 |
CP603956 | 3V | 3300mAh | 800mA | 1500mA | 6.1 | 39±0.5 | 56 |
CP604446-2S | 6V | 3000mAh | 2000mA | 4000mA | 13 | 46 | 44 |
CP603244 | 3V | 2000mAh | 1000mA | 1500mA | 6.2 | 32,5 | 44.5 |
CP702242 | 3V | 1500mAh | 200mA | 1200mA | 7 | 22 | 42 |
CP703028 | 3V | 1000mAh | 200mA | 400mA | 7 | 30 | 28 |
CP703448 | 3V | 2000mAh | 1000mA | 1500mA | 7 | 34 | 48.5 |
CP806468 | 3V | 8000mAh | 2000mA | 4000mA | 7.6 | 64 | 68 |
CP1002045 | 3V | 1800mAh | 900mA | 1500mA | 10.2 | 20.5 | 45.5 |
CP1002440 | 3V | 2400mAh | 400mA | 800mA | 10.2 | 25.5 | 40.5 |
CP1002550 | 3V | 2700mAh | 500mA | 1000mA | 10.2 | 25.5 | 50.5 |
CP4542100 | 3V | 4750mAh | 800mA | 1500mA | 4.5 | 42.5 | 100 |
CP7839109 | 3V | 9000mAh | 2000mA | 3000mA | 7.9 | 39±0.5 | 109 |
CP11568125 | 3V | 28000mAh | 4000mA | 6000mA | 12 | 68.5 | 126 |
CP9V | 9V | 1200mAh | 150mA | 300mA |
Application Field:
RFID BATTERY / ID card battery / Payment system battery etc
We can make Li-MnO2 soft battery as thin as 0.4-0.6mm, which is perfect for smart card, security card, RFID ,ETC and more applications.
NO MOQ with fast lead time.
Welcome for any customized.
Thanks.
Main points of flexible packaging lithium manganese battery
Flexible package structure design, special negative electrode structure design, self sealing diaphragm: improve battery safety;
Special raw material pretreatment: improve battery storage and comprehensive performance;
Continuous coating technology: improve battery performance, consistency and reliability;
Special electrolyte formula: improve battery environment, adaptability and storage performance;
HRL coating technology: improve battery safety performance and storage performance;
Battery integrated design technology: to ensure the highest safety performance of batteries, comprehensive design of the performance;
Large capacity flexible packaging lithium manganese battery technology: improve battery composition, group consistency;
Hybrid battery technology: both high specific energy and high pulse current performance.
