Product Details:
|
| Material: | Manganese Dioxide | Type: | Disposable |
|---|---|---|---|
| Voltage: | 9V | Capacity: | 1200mAh |
| Sample: | Available | Color: | Black Or Blue / Printed |
| High Light: | Manganese Dioxide Limno2 Lithium Battery,CR9V Limno2 Lithium Battery,1200mAh 9.0V Manganese Dioxide Battery |
||
Descriptions
| Type | Disposable battery | Non rechargeable battery |
| Name | Lithium Manganese Dioxide Battery | Limno2 battery |
| Model | CR9V | CP9V |
| Capacity | 1200mah | Single cell |
| Max. Discharge Current | 300mA |
At 23±2℃,battery discharge duration for 3 seconds and stand 27 seconds, it can discharge at least the max pulse discharge value which rated capacity 50% can permit |
|
Discharge Cut-off Voltage |
5.4 V | |
| Operating Temperature | -20℃~ +60℃ | Exceed the operating temperature range could lead to battery operating voltage reduction or even a security risk. |
| storage temperature | -5 ℃~+35℃ | 9.15V~9.75V |
| Storage life | 10 years |
Relative humidity Temperature -5 ℃~+35℃ |
| Cell Weight | Approx: 32 g | |
| Self Discharge Rate | 2% | Out of the recommended condition, the self-discharge rate 2% may increase. |
| Assemblage Dimension | Length:49.0mm Max Width:27.5 mm Max Thickness:17.5 mm Max |
Measured weight of 300gf at 25 ℃ ± 1 ℃.Not including battery connecting wire. |
Main points of flexible packaging lithium manganese battery
Flexible package structure design, special negative electrode structure design, self sealing
diaphragm: improve battery safety;
Special raw material pretreatment: improve battery storage and comprehensive performance;
Continuous coating technology: improve battery performance, consistency and reliability;
Special electrolyte formula: improve battery environment, adaptability and storage
performance;
HRL coating technology: improve battery safety performance and storage performance;
Battery integrated design technology: to ensure the highest safety performance of batteries,
comprehensive design of the performance;
Large capacity flexible packaging lithium manganese battery technology: improve battery
composition, group consistency;
Hybrid battery technology: both high specific energy and high pulse current performance.
