Place of Origin:
China
Brand Name:
OEM
Certification:
Meet UL
Model Number:
9V 1200mAh 9V Lithium Battery
9V Battery 1200mAh Lithium CR9V Batteries for Lifebuoy Pool Safety Alarm Ultra Lithium CR9V
CR9V-P Lithium Battery CR9V/P 9 V / PP3 battery Lithium 1200 mAh 9 V
CR9V can be used to replace the SA FT LS9V
Lithium-Manganese Dioxide Durable CR9V 9.0V 800mAh Battery
CR9V-FP Lithium Manganese Dioxide (Li-MnO2) 9V Battery
Type | Disposable battery | Non rechargeable battery |
Name | Lithium Manganese Dioxide Battery | Limno2 battery |
Model | CR9V | CP9V |
Capacity | 1200mah | Single cell |
Max. Discharge Current | 300mA |
At 23±2℃,battery discharge duration for 3 seconds and stand 27 seconds, it can discharge at least the max pulse discharge value which rated capacity 50% can permit |
Discharge Cut-off Voltage |
5.4 V | |
Operating Temperature | -20℃~ +60℃ | Exceed the operating temperature range could lead to battery operating voltage reduction or even a security risk. |
storage temperature | -5 ℃~+35℃ | 9.15V~9.75V |
Storage life | 10 years |
Relative humidity Temperature -5 ℃~+35℃ |
Cell Weight | Approx: 32 g | |
Self Discharge Rate | 2% | Out of the recommended condition, the self-discharge rate 2% may increase. |
Assemblage Dimension | Length:49.0mm Max Width:27.5 mm Max Thickness:17.5 mm Max |
Measured weight of 300gf at 25 ℃ ± 1 ℃.Not including battery connecting wire. |
Handling of cells:
★ Avoid any short-circuit. It will cause the leads to get hot and lose electronic functions.
★ Soft package is easily damaged by sharp objects such as needles and knives. Avoid
touching the cells
with sharp objects when handling and storing.
★ Next to the leads is the sealed edge. Don’t bend or fold the sealing edge as it is sensitive to
movement.
★ Don’t open the folded edge on the sides of the cell.
★ Don’t bend the tabs as the tabs are sensitive.
★ Avoid mechanical shock to the cells.
★ Don’t put the cells into an oven, washing machine or any high-voltage container.
★ Don’t use a charger without a safety certification. Use only a recommended charger.
★ You should immediately stop charging if the cell overheats, emits an odor, changes color,
changes
shape, etc.
★ Adults should supervise the use of batteries by children.
★ Before using batteries, please carefully read and understand the handling guidelines.
★ Avoid electro-static discharge when using, charging, and storing cells.
★ Avoid putting the battery in contact with metal conductors such as neck chains, barrettes, or
bolts, etc.
★ Don’t use metal conductors to connect the positive and negative leads together.
★ Avoid errors during assembly by contacting the positive lead with the negative lead.
Main points of flexible packaging lithium manganese battery
Flexible package structure design, special negative electrode structure design, self sealing
diaphragm: improve battery safety;
Special raw material pretreatment: improve battery storage and comprehensive performance;
Continuous coating technology: improve battery performance, consistency and reliability;
Special electrolyte formula: improve battery environment, adaptability and storage
performance;
HRL coating technology: improve battery safety performance and storage performance;
Battery integrated design technology: to ensure the highest safety performance of batteries,
comprehensive design of the performance;
Large capacity flexible packaging lithium manganese battery technology: improve battery
composition, group consistency;
Hybrid battery technology: both high specific energy and high pulse current performance.
Package:
