CP144920 150mah 3v Ultra Thin Soft Pack Li Mno2 Battery Lithium Manganese Dioxide Battery

cp144920 150mah 3v Ultra thin paper battery li-mno2 soft battery lithium manganese dioxide soft battery CP124920 primary lithium battery

CP144920 3V 150mAh Specialised Thin Cell Lithium Battery CP154920

The 3V 150mAh LiMnO2 Thin Cell Lithium battery part number can be CP124920 CP144920 CP154920 the same width and length, thickness from 1.2 to 1.5 mm

This is Limno2 battery in soft flexible design, looks like lithuim polymer battery ,but voltage 3.0volt , non rechargeable cell.

Main Characteristics:

a. High and stable working voltage

b. Wide operating temperature range

c. Longer storage life and higher reliability

d. High safety and non-pollution

Specification:

Application Field:

a. Civilian field: AMR of common instruments and CMOS circuit boards

b. Various smart meters: smart electric meters, water meters, heat meters and gas meters

c. Memories and standby power supplies: memory backup, clock power supplies and data backup power supplies

d. Radio alarm equipment/sensors: smoke alarms and temperature monitors

e. Remote monitoring systems: positioning devices and marine telemetry systems

f. Automotive electronics: tire pressure monitoring systems

g. Industrial field: automation instrumentations and equipment, oil wells, mines, medical equipment, burglar alarm, wireless communication, sea survival, etc.

h. Modern national defense and military fields: aviation, spaceflight, marine electronics, air-sea-land weapons, etc.

Main points of flexible packaging lithium manganese battery

Flexible package structure design, special negative electrode structure design, self sealing

diaphragm: improve battery safety;

Special raw material pretreatment: improve battery storage and comprehensive performance;

Continuous coating technology: improve battery performance, consistency and reliability;

Special electrolyte formula: improve battery environment, adaptability and storage

performance;

HRL coating technology: improve battery safety performance and storage performance;

Battery integrated design technology: to ensure the highest safety performance of batteries,

comprehensive design of the performance;

Large capacity flexible packaging lithium manganese battery technology: improve battery

composition, group consistency;

Hybrid battery technology: both high specific energy and high pulse current performance.

Battery Cell Performance Criteria

Standard testing environment

Unless specifically stated otherwise, tests must be done within one month of delivery and the

number of charging-recharging cycles is fewer than 5. The following is test conditions:

Test conditions:

Ambient Temperature: 25ºC ± 1ºC Ambient Humidity: 45~75%RH

The requirement of measure instrument

(1) The measurement instrument has been certified by a qualified source.

(2) The accuracy of the measuring instrument is less than 0.01mm.

(3) The accuracy of multimeter is at least 0.5%.

(4) The current accuracy of the battery test system is at least ±0.1%, isobarically accuracy is

±0.5%, and timer accuracy is not less than ±0.1%.

(5) The accuracy of the thermometer is at least ±0.5ºC.

 Visual inspection

Not allowing any visual defects which will affect the electronic characteristics, such as leakage

and damage.
