Product Details:
|
| Type: | 32650 Lithium Ion Battery 32700 | Part Number: | IFR32650 / IFR32700 |
|---|---|---|---|
| Rate: | 3C | Capacity: | 6000mah/5000MAH/4200MAH |
| Voltage: | 3.2v | Material: | Lifepo4 |
| High Light: | Phosphate Rechargeable Lithium Battery,IFR32700 Rechargeable Lithium Battery,UPS Lithium Iron Phosphate Battery |
||
3.7v 6000mah Phosphate Rechargeable Lithium Battery Lifepo4 32700 Cell
Lifepo4 32700 Battery cell 3.7v 6000mah li ion 6000 mah rechargeable lithium iron phosphate battery 3.2v
32700 lithium Battery Cell LiFePO4 6000mAh 32650 Battery 3.2V 6ah
3.2V 6Ah 32700 lithium Iron Phosphate Cells Lifepo4 Cylindrical Battery
Product Classification:Cylindrical Rechargeable Lithium-ion Cell
Model Name:LiFePO4-32700- 6.0Ah
Benefits:
Sturdy and pressure resistant steel envelope
High capacity
Excellent cycle life
Excellent high and low temperature performance
Steady output voltage
Low self-discharge
Double safety protection
With outstanding high level of vibrations and shocks
Main Application:
Electric two-wheeled vehicle, three-wheeled vehicle,
Four-wheeled low-speed vehicle
UPS
Storage energy
Features/Specs:
Chemistry: LiFePo4
Model: IFR 32700 IFR32650
Nominal Rated Voltage:3.2 V
Rechargeable: Yes
Nominal Capacity: 6000mAh
Maximum Discharge Current: 3C
Maximum Charge Voltage: 4.2±0.05V
Internal resistance: <13mΩ
Life Cycle: 1000 Times(Approx)
Color: Blue
Length: 70.50mm
Width: 32.44mm
Weight: 145g
IFR32700 lithim battery data sheet:
| Part number | IFR32700 |
| Capacity | 6000 mah |
| Charge limited voltage | 3.65v |
| Discharge cut-off voltage | 2.0v |
| Standard charge | 0.5C |
| Rapid charge | 1C |
| Rapid dishcarge | 1C |
| Max discharge | 3C |
| Shipping voltage | 3.1~3.35v |
| Weight | 145g |
| Cell model | Voltage/V | Capacity/mAh | Capacity/mAh | Charge current | Discharge current | |||
| Standard | Max. | Standard | Rapid | Max. | ||||
| IFR18650-1600mAh-3.2V | 3.2 | 1600 | ≥1550 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR18650-1800mAh-3.2V | 3.2 | 1800 | ≥1750 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3200mAh-3.2V | 3.2 | 3200 | ≥3100 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3600mAh-3.2V | 3.2 | 3600 | ≥3550 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-3800mAh-3.2V | 3.2 | 3800 | ≥3750 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFR26650-4000mAh-3.2V | 3.2 | 4000 | ≥3950 | 0.5C | 1C | 0.5C | 1C | 3C |
| IFRP18650-1100mAh-3.2V | 3.2 | 1100 | ≥1050 | 2C | 5C | 5C | 10C | 30C |
| IFRP26650-3000mAh-3.2V | 3.2 | 3000 | ≥2900 | 1C | 3C | 2C | 5C | 10C |
| INR18650-2200mAh-3.6V | 3.6 | 2200 | ≥2150 | 0.5C | 1C | 0.5C | 1C | 3C |
| INR18650-2600mAh-3.6V | 3.6 | 2600 | ≥2550 | 0.3C | 0.5C | 0.5C | 1C | 2C |
| INR26650-5000mAh-3.6V | 3.6 | 5000 | ≥4900 | 0.5C | 1C | 0.5C | 1C | 2C |
High energy particle density.
Always stable with a certain voltage.
Reduce environmental pollution.
Long service life
Safe
Capacity and voltage are always stable.
High safety when the battery automatically disconnects when fully charged.
Batteries are manufactured and distributed from the factory
1-way current, low self-discharge capacity
Battery covered by PVC
Power backups/UPS
Laptops, and other commonly used consumer electronic goods
Electric mobility
Energy Storage Systems
Flashlight
power bank etc.
